Model information
Everything documented for this model
Feature availability is model-specific. Review the complete product information before configuring a battery system.
Latest V8 version BMS.
Bluetooth BMS, Self-heater pad .
Description
7 Years Warranty,3000~8000 Cycles Life Span,Free Maintenance.
Detachable Cover,Replaceable BMS or Cells.
Connect in series for 24V or 36V or 48V Battery Bank, or Connect in Parallel for Larger Capacity.
Built-in Smart Battery Management System.
Built-in heater pad for using in down to -4°F
Low Temperature Charging Cut-off.
High Temperature Charging or Discharging Cut-off.
Over Charging or Discharging Protection.
Over Current & Short Circuit Protection.
Battery Cells Auto Balance.
Notice for connect in series: If you need connect batteries in series, they should be at the same state-of-charge (SOC)before they are connected.
Spec Information
Charge information:
Recommend charge current: 40A
Maximum charge current: 70A
Recommend charge voltage:14.4V ~14.6V
Maximum batteries in series: 4PCs batteries.
Discharge Information:
Maximum continuous discharge current: 170A
Peak discharge current: 200A(3 seconds)
Recommend low voltage disconnect: 11.2V
BMS discharge cut-off voltage: Around 10.4V
Reconnect Voltage:>11.6V
Size Information:
Terminal Type: M8, 5/16 lugs
Weight: 48 lbs.
Temperature Information:
Discharge temperature:-4°F~140°F
Charge temperature: 32°F~113°F
Recommend storage temperature:23°F~95°F
Certifications Information:
UL1973&IEC62619 for Battery cells.
Downloads
Please login for download
Spec Sheet & User manual:
Model-specific data
Technical specifications
- Voltage
- 14.6V
- Capacity
- 2637Wh
- Continuous current
- 170A Continuous, 200A Peak
- Cycle life
- 4000+ cycles
- Warranty
- 7 years
